Model

ENS620EXT

Standards

IEEE 802.11b/g/n on 2.4 GHz

IEEE802.11a/n/ac on 5 GHz

Processor

Qualcomm® 717 MHz Quad-Core CPU

4x ARM Cortex A7

Memory Capacity

Memory: 256 MB

Flash Memory 32 MB

Antennas

Four (4) External 5 dBi Dual-Concurrent Omni-Directional Antennas

SMA-Type

Physical Interface

2 x 10/100/1000 Gigabit Ethernet Port

1 x Reset Button

Power Source

Power-over-Ethernet: Proprietary 24V PoE IEEE 802.11e Compliant Source

Active Ethernet (PoE)

LED Indicators

1 x Power

2 x LAN

1 x 2.4 GHz

1 x 5 GHz

Operating Frequency

Dual-Radio Concurrent 2.4 GHz & 5 GHz

Multiple BSSID

Supports up to 16 SSIDs, 8 SSIDs per radio

Operation Modes

Access Point Mode (AP mode)

Client Bridge Mode (CB mode)

WDS: AP Mode and Bridge Mode

Wireless Security

WEP Encryption 64/128/152 bit

WPA/WPA2 Enterprise (WPA-EAP using TKIP or AES)

Hide SSID in Beacons

MAC Address Filtering, Up to 64 MACs per SSID

Wireless STA (Client) Connected List

SSH Tunnel

Client Isolation

Temperature Range

Operating: 32º F~104º F (0º C~40º C)

Storage: -22º F~176º F (-40º C~80º C)

Humidity (non-condensing)

Operating: 90% or less

Storage: 90% or less

Dimensions & Weights

Weight: 1.11 lbs (504 g)

Width: 7.54” (191.6 mm)

Length: 4.49” (114.3 mm)

Height” 1.88” (47.7 mm)

Package Contents

1-ENs620EXT Dual-Band AC1300 Outdoor Access Point

1-PoE Adapter (EPA2410GP)

2-Pole Mounting Brackets

1-Wall-Mount Screw Set

2-2.4 GHz 5dbi SMA Antennas

2-5 GHz 5dbi SMA Antennas

1-Power Cord

Quick Installation Guide
