Model

EWS357AP

Standards

802.11a/b/g/n/ac/ax

Antennas

Integrated Omni-Directional Antenna

2 x 3 dBi @ 2.4 GHz

2 x 3 dBi @ 5 GHz

Processor

Qualcomm® Quad-Core CPU ARM Cortex A53s @ 1.0GHz

Physical Interface

1 x 10/100/1000 BASE-T, RJ-45 Gigabit Ethernet Port

1x DC Jack

1 x Reset Button

Power Source

Power Supply: 100 to 240 VDC ± 10%, 50/60 Hz (depends on different countries)

Active Ethernet (Power-over-Ethernet, IEEE 802.3at/af)

12VDC/2A Power Adapter

LED Indicators

1 x Power

1 x LAN

1 x 2.4 GHz

1 x 5 GHz

Operating Frequency

Dual-Radio Concurrent 2.4 GHz & 5 GHz

Operation Modes

Managed mode: AP, AP Mesh, Mesh

Stand alone: AP, AP Mesh, Mesh

Wireless Security

WPA3

WPA2 Enterprise (AES)

Hide SSID in Beacons

MAC Address Filtering, Up to 32 MACs per SSID

Wireless STA (Client) Connected List

SSH Tunnel

Client Isolation

Temperature Range

Operating: 32º F~104º F (0º C~40º C)

Storage: -22º F~176º F (-40º C~80º C)

Humidity (non-condensing)

Operating: 90% or less

Storage: 90% or less

Dimensions & Weights

Weight: TBD

Length: 6.30” (160 mm)

Width: 6.30” (160 mm)

Height: 1.31” (33.2 mm)

Package Contents

1 – Ceiling Mount Base (9/16” Trail)

1 – Ceiling Mount Base (15/16” Trail)

1 – Ceiling and Wall Mount Screw Kits

1 – Quick Installation Guide
