Feature

Description

Routing

- Static routing

- Dynamic routing

- Routing Information Protocol (RIP) v1 and v2

- Inter-VLAN routing

Layer 2

- 802.1Q-based VLANs

- 4 active VLANs (3 to 4094 range)

Network

- Dynamic Host Configuration Protocol (DHCP) server

- Point-to-Point Protocol over Ethernet (PPPoE)

- Point-to-Point Tunneling Protocol (PPTP)

- Layer 2 Tunneling Protocol (L2TP)

- DNS proxy

- DHCP relay agent

- IGMP Proxy and multicast forwarding

- Internet Group Management Protocol (IGMP) proxy and multicast forwarding

- Rapid Spanning Tree Protocol (RSTP)

- Dynamic DNS (DynDNS), TZO, 3322.org)

- Network Address Translation (NAT), Port Address Translation (PAT)

- Port management

- Port Mirroring

- Software-configurable network edge (DMZ) to any LAN IP address

IPv6

- Dual-stack IPv4 and IPv6

- 6to4 tunneling

- Multicast Listener Discovery (MLD) for IPv6 (RFC 2710)

- Stateless address auto-configuration

- DHCP v6 Server for IPv6 Clients on LAN

- DHCP v6 client for WAN connectivity

- Internet Control Message Protocol (ICMP) v6

- Static IPv6 Routing

- Dynamic IPv6 Routing with RIPng

- IPv6 Rapid Deployment

Security

- Stateful packet inspection (SPI) firewall

- Port forwarding and triggering

- Firewall Access Control Lists and Content Filtering

- Denial-of-service (DoS) prevention

- MAC-based wireless access control

- Static URL blocking or keyword blocking

- Schedule-based Internet access policy

- HTTPS web access to the device manager

- Username/password complexity enforcement

- Self-signed SSL certificate

- Import and export certificate using Privacy-Enhanced Mail (PEM) format

VPN

- 5 IPsec client sessions using Cisco QuickVPN client

- 5 PPTP client sessions for remote client access

- Triple Data Encryption Standard (3DES) VPN pass-through of PPTP, L2TP, and IPsec

- 1 IPSec Site-to-Site tunnel

Quality of service (QoS)

- 802.1p port-based priority on LAN port, application-based priority on WAN port

- 4 queues

- Differentiated Services Code Pointsupport (DSCP)

- Class of Service (CoS)

- Bandwidth Management for service prioritization

Management

- Simple Network Management Protocol (SNMP) v3

- Event logging: local, syslog, email alerts

- Firmware upgradable through web browser

- Imported/exported configuration in text format

- Simple browser-based configuration (HTTP/HTTPS)

- Bonjour and Universal Plug and Play (UPnP)

- Network diagnostics: Ping, Traceroute, and DNS Lookup

Performance

- NAT throughput: 90 Mbps

- Concurrent sessions: 5,000

- VPN throughput: 5Mbps

Feature

Description

WLAN hardware

IEEE 802.11n standard-based access point with 802.11b/g compatibility

Radio and modulation type:

- 802.11b: direct sequence spread spectrum (DSSS)

- 802.11g/n: orthogonal frequency division multiplexing (OFDM)

- 2 omnidirectional 1.8 dBi gain fixed external antennas

Operating channels:

- 11 in North America

- 13 in most of Europe

- Automatic channel selection

Transmit power:

- 802.11b: 17 dBm +/- 1.5 dBm

- 802.11g: 15 dBm +/- 1.5 dBm

- 802.11n: 12.5 dBm +/- 1.5 dBm

Receiver sensitivity:

- -87 dBm at 11 Mbps

- -71 dBm at 54 Mbps

- -68 dBm at msc15, HT20 / -66dBm at mcs15, HT40

Wireless Domain Services (WDS)

- Allows wireless signals to be repeated by up to 3 compatible devices

Wi-Fi Multimedia (WMM)

- WMM with QoS (802.11e), WMM power save (WMM-PS)

Active WLAN clients

- Up to 32 clients

Service Set Identifiers (SSIDs)

- Up to 4 separate wireless networks

Wireless isolation

- Wireless isolation between clients

WLAN security

- WPS ( Wi-Fi Protected Setup), Wired Equivalent Privacy (WEP), Wi-Fi Protected Access (WPA) personal and enterprise, WPA2 personal and enterprise

Feature

Description

WAN

One 10/100 Mbps Fast Ethernet WAN port

LAN

Four 10/100 Mbps Fast Ethernet LAN ports

WLAN

Built-in 802.11n wireless access point

LEDs

Power, WPS, WAN, Wireless, LAN (ports 1-4)

Switch

Power button (on/off)

Physical dimensions and weight

- W x D x H = 5.91 in. x 5.91 in. x 1.18 in. (150 mm x 150 mm x 30 mm)

- Weight: 0.61 lb (0.3 kg)

Power

12V 1A

Certifications

- FCC Class B

- CE

- IC

- cUL

- Wi-Fi

Environmental operating range

- Operating temperature: 0° to 40°C (32° to 104°F)

- Storage temperature: -20° to 70°C (-4° to 158°F)

- Operating humidity: 10% to 85% noncondensing

- Storage humidity: 5% to 90% noncondensing
