Specifications

Media

 Single-mode fiber (SMF)

Application

 1000BASE-BX-20U

Connector type

 Single LC

Wavelength typical (Tx)

 1310 nm

Wavelength range (Rx)

 1490 nm

Performance

Maximum distance

 up to 20 km

Average output power

 -8 dBm to -3 dBm

Receiver sensitivity

 -23 dBm (typ)

Receiver overload

 -3 dBm

Environmental

Dimensions

W x H x D

 13.4 x 8.5 x 55.7 mm (0.53 x 0.33 x 2.19 in.)

Unit weight

0.018 kg (0.63 oz. )

Power

1W (max)

Operating temperature

32º to 158ºF (0º to 70ºC)

Storage temperature

-40º to 185ºF (-40º to 85ºC)

Operating humidity

10% to 85% noncondensing

Storage humidity

5% to 90% noncondensing

Standards

Compliance

FCC Part 15 Class B

EN55022 Class B (CISPR 22B)

VCCI Class B

Safety

FDA 21 CFR 1040.10 and 1040.11

EN60950, EN (IEC) 60825-1,2
