Hardware Specifications

Interfaces LAN

1 x 10/100/1000Base-T RJ45 port

Auto-negotiation and Auto MDI/MDI-X

Antennas Gain

2 x 2.4GHz 2.5dBi PCB antenna

2 x 5GHz 4dBi PCB antenna

Reset Button

Reset button on the top cover

Press over 7 seconds to reset the device to factory default

LED Indicators

PWR

Allow LED to turn off via software control

Wireless Interface Specifications

Standard

IEEE 802.11ac (Draft 2.0) 5GHz

IEEE 802.11a/n 5GHz

IEEE 802.11b/g/n 2.4GHz

Antenna Structure

802.11ac: 2T2R MU-MIMO

802.11n: 2T2R MIMO

Modulation

DSSS

Data Modulation

802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)

802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)

802.11b: DSSS (DBPSK / DQPSK / CCK)

Band Mode

2.4GHz / 5GHz concurrent mode

Frequency Range

2.4GHz: America/ FCC: 2.412~2.462GHz

Europe/ ETSI: 2.412~2.484GHz

5GHz: America/ FCC: 5.180~5.240GHz, 5.725~5.850GHz

Europe/ ETSI: 5.180~5.240GHz

Operating Channels

2.4GHz: America/ FCC: 1~11

Europe/ ETSI: 1~13

5GHz: America/ FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165

Europe/ ETSI: 36, 40, 44, 48

Channel Width

802.11ac: 20/40/80MHz

802.11n: 20/40MHz

Transmission Distance

802.11ac (draft): up to 30m

802.11n: up to 70m

802.11g: up to 30m

Max. RF Power

5GHz:

802.11ac (VHT20): 15.5dBm

802.11ac (VHT40): 15.5dBm

802.11ac (VHT80): 15.5dBm

802.11n (HT20): 15.5dBm

802.11n (HT40): 15.5dBm

802.11a: 15.5dBm

2.4GHz:

802.11n: 17 ±2.5dBm

802.11b/g: 20 ±2.5dBm

Software Features

Wireless Mode

Universal Repeater (AP+Client)

Repeater (WDS+AP)

AP (Access Point)

WDS PTP (Point to Point)

WDS PTMP (Point to Multipoint)

Client

Encryption Security

WEP (64/128-bit) encryption security

WPA / WPA2 (TKIP/AES)

WPA-PSK / WPA2-PSK (TKIP/AES)

Wireless Security

Provides wireless LAN ACL (Access Control List) filtering

Wireless MAC address filtering

Supports WPS (Wi-Fi Protected Setup)

Enable/ Disable SSID Broadcast

Wireless Advanced

WMM (Wi-Fi Multimedia): 802.11e Wireless QoS

Multiple SSID: up to 5 at 2.4GHz and 5GHz, respectively

Wireless Isolation: Enables to isolate each connected wireless client from communicating with each other

IAPP (Inter Access Point Protocol): 802.11f Wireless Roaming

Provides Wireless Statistics

Max. Clients

Wire: 253

2.4GHz Wireless: 32

5GHz Wireless: 32

LAN

Built-in DHCP server supporting static IP address distributing

Supports UPnP

Supports 802.1d Spanning Tree

Standards Conformance

IEEE Standards

IEEE 802.11ac (Draft 2.0, 2T2R, up to 867Mbps)

IEEE 802.11n (2T2R, up to 300Mbps)

IEEE 802.11g

IEEE 802.11b

IEEE 802.11i

IEEE 802.3 10Base-T

IEEE 802.3u 100Base-TX

IEEE 802.3ab 1000Base-T

IEEE 802.3x Flow Control

Other Protocols and Standards

CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, SNTP

Power Requirements

802.3at PoE, 48-56VDC input

Power Consumption

20W (max.)

Mounting

Ceiling Mount

Material

Plastic

Dimensions (Φ x H)

194 x 49 mm

Weight

300 ±5g
