Output

Output power capacity

2.7 KWatts / 3.0 kVA

Max Configurable Power (Watts)

2.7 KWatts / 3.0 kVA

Nominal Output Voltage

230V

Output Voltage Distortion

Less than 5%

Output Frequency (sync to mains)

50/60Hz +/- 3 Hz

Other Output Voltages

208, 220, 240

Load Crest Factor

3:1

Topology

Line Interactive

Waveform type

Sine wave

Output Connections

(2) IEC 320 C19 (Battery Backup)

(2) IEC Jumpers (Battery Backup)

(8) IEC 320 C13 (Battery Backup)

Transfer Time

2-4 ms, 6ms typical: 10ms maximum

Input

Nominal Input Voltage

208V, 230V

Input frequency

50/60 Hz +/- 3 Hz (auto sensing)

Input Connections

IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A

Cord Length

1.83meters

Input voltage range for main operations

140 - 280V

Number of Power Cords

1

Other Input Voltages

220, 240

Transfer Time

2-4 ms

Batteries & Runtime

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof

Typical recharge time

3hour(s)

Expected Battery Life (years)

3 – 5

RBC Quantity

1

Extendable Run Time

1

Battery Volt-Amp-Hour Capacity

738

Communications & Management

Interface Port(s)

SmartSlot

Control panel

LED status display with On Line: On Battery: Replace Battery and Overload indicators, Multi-function LCD status and control console

Audible Alarm

Alarm when on battery: distinctive low battery alarm: configurable delays

Emergency Power Off (EPO)

Yes

Available SmartSlot™ Interface Quantity

1

Rack height

4U

Dimension

432 x 178 x 483mm

Weight

38.64kg
