Output

Output power capacity

8.0 KWatts / 8.0 kVA

Max Configurable Power (Watts)

8.0 KWatts / 8.0 kVA

Nominal Output Voltage

230V

Output Voltage Distortion

Less than 2%

Output Frequency (sync to mains)

50/60Hz +/- 3 Hz

Other Output Voltages

220, 240

Load Crest Factor

3:1

Topology

Double Conversion Online

Waveform type

Sine wave

Output Connections

(1) Hard Wire 3-wire (H N + G) (Battery Backup)

(4) IEC 320 C19 (Battery Backup)

(3) IEC Jumpers (Battery Backup)

(6) IEC 320 C13 (Battery Backup)

Bypass

Internal Bypass (Automatic and Manual)

Input

Nominal Input Voltage

230V, 400V 3PH

Input frequency

40 - 70 Hz (auto sensing)

Input Connections

Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G)

Input voltage range for main operations

160 - 275V

Input voltage adjustable range for mains operation

100 - 275 (half load), 173 - 476 (half load)V

Other Input Voltages

220, 240

Batteries & Runtime

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof

Typical recharge time

1.5hour(s)

Replacement Battery

APCRBC140

Expected Battery Life (years)

3 – 5

RBC Quantity

2

Extendable Run Time

1

Battery Volt-Amp-Hour Capacity

1728

Communications & Management

Interface Port(s)

RJ-45 Serial, Smart-Slot , USB

Control panel

Multi-function LCD status and control console

Audible Alarm

Audible and visible alarms prioritized by severity

Emergency Power Off (EPO)

Yes

Available SmartSlot™ Interface Quantity

1

Dimension

432 x 263 x 715mm

Weight

111.82kg
