Output

Output Power Capacity

700 Watts / 1000 VA

Max Configurable Power (Watts)

700 Watts / 1000 VA

Nominal Output Voltage

230V

Output Voltage Note

Configurable for 220: 230 or 240 nominal output voltage

Output Voltage Distortion

Less than 5% at full load

Output Frequency (sync to mains)

47 - 53 Hz for 50 Hz nominal , 57 - 63 Hz for 60 Hz nominal

Other Output Voltages

220, 240V

Topology

Line Interactive

Waveform Type

Sine wave

Output Connections

(2) IEC Jumpers (Battery Backup) , (4) IEC 320 C13 (Battery Backup)

Input

Nominal Input Voltage

230V

Input Frequency

50/60 Hz +/- 3 Hz (auto sensing)

Input Connections

IEC-320 C14

Input voltage range for main operations

160 - 286 V

Input voltage adjustable range for mains operation

151 - 302V

Other Input Voltages

220, 240

Battery Type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte :

Leakproof

Typical recharge time

3 hour(s)

Replacement Battery

APCRBC132

RBC Quantity

1

Interface Port(s)

RJ-45 Serial , SmartSlot , USB

Available SmartSlot™ Interface Quantity

1

Control panel

Multi-function LCD status and control console

Audible Alarm

Alarm when on battery: distinctive low battery alarm: configurable delays

Emergency Power Off (EPO)

Optional

Surge energy rating

459 joules

Filtering

Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449

Rack height

2U

Dimension

89 x 432 x 457mm

Weight

28.18 kg
