Output

Output Power Capacity

1000 Watts/ 1500VA

Max Configurable Power

1000 Watts/ 1500VA

Nominal Output Voltage

230V

Output Voltage Note

Configurable for 220: 230 or 240 nominal output voltage

Output Voltage Distortion

Less than 5% at full load

Output Frequency (sync to mains)

47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal

Other Output Voltages

220, 240

Topology

Line Interactive

Waveform Type

Sine wave

Output Connections

(4) IEC 320 C13

(2) IEC Jumpers

Input

Nominal Input Voltage

230V

Input Frequency

50/60 Hz +/- 3 Hz (auto sensing)

Input Connections

IEC-320 C14

Input voltage range for main operations

160 - 286V

Input voltage adjustable range for mains operation

151 - 302V

Other Input Voltages

220, 240

Batteries & Runtime

Battery Type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof

Typical recharge time

3 hour(s)

Replacement Battery

APCRBC133

RBC™ Quantity

1

Communications & Management

Interface Port(s)

RJ-45 Serial, SmartSlot, USB

Available SmartSlot™ Interface Quantity

1

Control panel

Multi-function LCD status and control console

Audible Alarm

Alarm when on battery: distinctive low battery alarm: configurable delays

Emergency Power Off (EPO)

Optional

Surge Protection and Filtering

Surge energy rating

459 Joules

Filtering

Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449

Rack Height

2U

Dimension

89 x 432 x 457mm

Weight

28.64kg
