Output

Output power capacity

1.98 KWatts / 2.2 kVA

Max Configurable Power (Watts)

1.98 KWatts / 2.2 kVA

Nominal Output Voltage

230V

Output Voltage Distortion

50/60Hz +/- 3 Hz

Other Output Voltages

208, 220, 240

Topology

Line Interactive

Waveform type

Sine wave

Output Connections

(8) IEC 320 C13 (Battery Backup)

(2) IEC Jumpers (Battery Backup)

(1) IEC 320 C19 (Battery Backup)

Transfer Time

2-4 ms, 6ms typical: 10ms maximum

Input

Nominal Input Voltage

208V, 230V

Input frequency

50/60 Hz +/- 3 Hz (auto sensing)

Input Connections

IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A

Cord Length

1.83meters

Input voltage range for main operations

140 - 280V

Number of Power Cords

1

Other Input Voltages

220, 240

Transfer Time

2-4 ms

Batteries & Runtime

Battery type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof

Typical recharge time

3hour(s)

Expected Battery Life (years)

3 – 5

RBC Quantity

1

Extendable Run Time

1

Battery Volt-Amp-Hour Capacity

702

Communications & Management

Interface Port(s)

SmartSlot, USB

Control panel

LED status display with On Line: On Battery: Replace Battery and Overload indicators, Multi-function LCD status and control console

Audible Alarm

Alarm when on battery: distinctive low battery alarm: configurable delays

Emergency Power Off (EPO)

Yes

Available SmartSlot™ Interface Quantity

1

Rack Height

2U

Dimension

85 x 432 x 667mm

Weight

37.32kg
